    Shantui bulldozer SD22C adapt to transfering, paving and stacking operations in coal mines

    Ask Lasest Price
    Brand Name : SINOMTP
    Model Number : SD22C
    Certification : ISO/CCC/BV
    Price : Negotiation
    Supply Ability : 100 units/month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Shantui bulldozer SD22C adapt to transfering, paving and stacking operations in coal mines

    Shantui bulldozer SD22C adapt to transfering, paving and stacking operations in coal mines


    Specification:


    ITEMSD22CEngineCummins
    NT855-C280S10
    L×W×H (Ripper not included)5750×4200×3395mmRipping depth of ripperSingle ripper 695mm
    Operating weight (Ripper not included)24.6tThree-shank ripper 666mm
    Rated power162/1800kW/rpmLifting height of ripperSingle ripper515mm/Three-shank ripper 555mm
    Gradeability30°Number of carriers (each side)2
    Blade typeCoal bladeNumber of track rollers (each side)6
    Blade width4200×1350mmNumber of track shoes (each side)38
    Width of track shoe660mm
    Track gauge2000mm
    Ground length and ground pressure2730-0.066mm/MPa
    Dozing capacity9m3Pitch216mm
    Forward speed0–3.6km/h
    0–6.5km/h
    0–11.2km/h
    Ma× drop below ground of blade540 mmReverse speed0–4.3km/h
    Lift height of blade1210 mm0–7.7km/h
    Ripper typeSingle ripper Three-shank ripper0–13.2km/h

    Description:


    The SD22C coal bulldozer is a modified form of the SD22, featuring advanced performance, high reliability, low fuel consumption and convenient maintenance.


    Advantage:


    1.The SD22C has a high-capacity coal-dozing blade, and is equipped with an engine intake pre-filtering device, helping adapt it to transferring, paving and stacking operations often performed in coal mines and electricity coal yards.

    2. The SD22 uses Shantui's patented central lubrication technology, central pressure measurement and automatic track tension, as well as a GPS satellite positioning system.

    With options such as straight tilt, angle, U type and semi-U type blades, single/triple shank rippers and a mechanical winch, the SD22 has various capabilities allowing it to adapt to and work in a wide range of earth moving projects.
